PRODUCT DESCRIPTION
From the leader in residential indoor air quality, this under-cabinet range hood by Broan-NuTone is built to surpass industry standards with over 50 points of inspection, engineered as a reliable ventilation solution. The durable hood vent is equipped with SmartSense Auto Operation that automatically monitors and adjusts the ventilation power needed based on heat coming off the cooktop to maintain the integrity of the IAQ in your space. This is the most powerful under-cabinet in our assortment at 640 Max Blower CFM, and the EZ1 Install System allows for a quick and easy 1-person installation. This ENERGY STAR Certified unit is code compliant and provides cost savings, and the 2-Level LED lighting modules and a 3-Speed whisper touch infrared control make cooking a breeze. At Broan-NuTone we believe that better quality of air means better quality of life.
Specifications
Filter Type
Hybrid Baffle
Heat Sentry(TM)
No
HVI Certified
Yes
Lighting Type
LED
Sound Level (Sones)
0.8
UL Listed
No
ADA Compliance
Yes
Damper Included
Yes
ENERGY STAR(R) certified
Yes
Light Bulb Wattage
5
Light Bulbs Included
Yes
Light Levels
2
Material
Stainless Steel
Nightlight Or Nighlight Setting
No
Ductless Recirculation Capable
Yes
Ductless Filter Or Kit Included
No
Remote Operation Capable
No
Speed Levels
3
Switch Control Type
Infrared
Rated Voltage
120
Boost Mode
No
Country of Origin
China
Minimum Height Above Cook Top
18
Rated Amps
2
Product Depth
20.06
Product Height
5.12
Product Width
30"
Built-In Timer
No
Capture Efficiency
98.5
CFM
570
Diameter
3.25 x 10-inch;7-inch round
Vent Type
Convertible Built-In
Duct Direction
Horizontal/Vertical
Bulb (Recommended Type)
Integrated LED Module
Manufacturer Warranty
1 Year, 3 Year LED module
Wattage
228
50 Points of Inspection: Expect a durable, long-standing ventilation solution engineered by the leader in indoor air quality
Most Powerful Under-Cabinet: At 640 Max Blower CFM, this is the strongest vent hood in our under-cabinet line up, providing the power needed to handle heavy cooking and clear pollutants from the home.
Both ENERGY STAR certified and Title 24 compliant, this kitchen hood is energy efficient and code compliant
Bright 2-level, heat resistant LED modules (included) to enhance your cooking experience
Easy-to-clean, fully enclosed bottom with 2 dishwasher-safe high efficiency hybrid baffle filters
The infrared controls allow for manual operation to adjust the 3-speed blower and 2 level lighting
Convertible to accommodate either top or rear venting applications or non-ducted operation using charcoal filters, which are sold separately (Filter Model HPF30)
Range hood is installed as hardwired or with an optional power cord kit (HCK44; sold separately)
Can be used with optional Universal make-up air damper MD6TU, MD8TU or MD10TU to replace air exhausted out of the house only when the hood is turned ON, helping with ventilation to keep your home fresh while reducing energy consumption
Can be installed for ADA Compliance with the purchase of model HAWRK5 low voltage wiring and wall switch kit
SmartSense(TM) Automated Ventilation: Expel pollutants from your home without thought or action; An infrared sensor monitors for heat coming off the range and will automatically adjust the hood's fan speed as needed to eliminate smoke and odors while cooking
One Person Installation: With the included EZ1 brackets it's an easy install for a single person in half the time, both professional and DiYers
Code Ready Technology (CRT): Supports the installer's job with the ability to reduce airflow to 300 or 400 CFM to address local codes or make-up air requirements
