PRODUCT DESCRIPTION
Specifications
Width
30 , 36
Sones
4.1
Extraction capacity
300 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
14.00
NET WEIGHT (kg)
10.40
CARTON LENGHT (mm)
249.00
CARTON HEIGHT (mm)
632.00
CARTON WIDTH (mm)
864.00
VOLUMEN (M3)
0.10
SHIPPING WEIGHT
30.86
NET WEIGHT
22.93
CARTON LENGHT
9.80
CARTON HEIGHT
24.88
CARTON WIDTH
34.02
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
White
Color
white matte
Type of Ventilation
Convertible
HOODS FEATURES
3x layer mesh, Led light
WIDTH (IN)
30"
WIDTH (CM)
76.00
AIRFLOW (M3/H)
510.00
CFM (MAX)
300.00
db (min)
36.00
db (max)
51.00
SONES
1.7 - 5.0
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Rectangular 10 x 3 1/4"
DUCT SHAPE
Rectangular
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
10"
RECTANGULAR DUCT WIDTH
3.25
Round duct diameter
NA
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
2.3 A
HERTZ
60.00
WATTS
255.00
LIGHTING
LED 2 x 2.1 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
2.10
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Soft touch buttons w/blue illumination
SPEED CONTROL
YES
NUMBER OF SPEEDS
3.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
NA
DIMENSIONS
76 x 51 x 12
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
4 3/4"
Maximum Overall Height - Top to Bottom
4 3/4"
Overall Height - Top to Bottom
4 3/4"
Overall Width - Side to Side2
30"
Overall Depth - Front to Back
20"
Hood Height
4 3/4"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
KIT02178
CHIMNEY EXTENSION NUMBER
NA
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
KIT02723
NON RETURN VALVE
-
UPGRADE FILTER
GRI0131086A
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
NA
DIMENSIONS inches
30" x 20" x 4 3/4"
Prop65 Disclosure
YES
GTIN
00190603000658
EAN
0190603000658
UPC
190603000658
3x layer mesh
Led light
