Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
12.60
CARTON LENGHT (mm)
837.00
CARTON HEIGHT (mm)
426.00
SHIPPING WEIGHT (lb)
27.78
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Type of Ventilation
Convertible
HOODS FEATURES
3x layer mesh,Led light
EXHAUST VERSION
Convertible with Kit
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
LED 2 x 2.1 ww 4000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Backlit Electronic Push Button
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
57 x 27 x 24
DIMENSIONS_x000D_ (INCH)
22 1/2" x 10 3/4 x 9 1/2
Minimum Overall Height - Top to Bottom
9 1/2"
Maximum Overall Height - Top to Bottom
14 9/16
Overall Height - Top to Bottom
9 1/2"
Overall Width - Side to Side2
22 1/2"
Overall Depth - Front to Back
10 3/4
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
NA
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
COMFORT SILENCE America
0.00
SEI (SUPER EASY INSTALLATION) America
0.00
Delay switch off America
0.00
LONG LIFE FILTER America
0.00
TOTAL INTEGRATION America
0.00
PERIMETER ASPIRATION America
0.00
3X LAYER MESH FILTER
2.00
PROFESSIONAL PERFORMANCE
0.00
REAR OUTLET INSTALLATION
0.00
CFM Reduction System
0.00
RECIRCULATION KIT
KIT02770
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600/1200 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 " round deflector
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation 4 round carbon filters
NA
Recirculation(8 round deflector)
NA
Long Chimney Ext/Chimney extension
NA
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension_x000D_ (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
NA
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
CFM REDUCTION KIT
KIT0175561
INLINE BLOWER (1200CFM)
NA
EXTERNAL BLOWER (1200 CFM)
NA
INLINE BLOWER SHELL KIT (600 CFM)
NA
INLINE BLOWER SHELL KIT
NA
EXTERNAL BLOWER SHELL KIT
NA
HIGH CEILING EXTENSION KIT
NA
Duct cover extension 6
NA
Duct cover extension 18
NA
ELECTRONIC CFM REDUCTION BYPASS
NA
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
VERSION ADVANCES
REAR OUTLET
