PRODUCT DESCRIPTION
Specifications
Width
30 , 36
Sones
6
Extraction capacity
600 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
19.10
NET WEIGHT (kg)
13.80
CARTON LENGHT (mm)
1027.00
CARTON HEIGHT (mm)
675.00
CARTON WIDTH (mm)
369.00
VOLUMEN (M3)
0.30
SHIPPING WEIGHT
42.11
NET WEIGHT
30.42
CARTON LENGHT
40.43
CARTON HEIGHT
26.57
CARTON WIDTH
14.53
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Convertible
HOODS FEATURES
Semi baffle filter, Hush system, Led light, CFM reduction system
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
15.00
db (max)
52.00
SONES
0.4 - 5.2
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3,7 A
HERTZ
60.00
WATTS
265.00
LIGHTING
LED 2 x 2.1 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
2.10
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Stainless Steel Baffle Slot Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Touch Controls with Adjustable Color Backlight
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
Yes
DIMENSIONS
91 x 50 x 72
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
28 3/8"
Maximum Overall Height - Top to Bottom
42 1/8"
Overall Height - Top to Bottom
28 3/8"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
19 11/16"
Hood Height
10 1/4"
Minimum Compatible Ceiling Height
7'5"
Maximum Compatible Ceiling Height
9'6"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
8 3/16"
Chimney Depth - Front to Back
7 3/16"
Chimney Height - Top to Bottom
31 7/8 "
RECIRCULATION KIT NUMBER
KIT02766
CHIMNEY EXTENSION NUMBER
KIT02762
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
NA
DIMENSIONS inches
36" x 19 11/16" x 28 3/8"
Prop65 Disclosure
YES
GTIN
00190603005530
EAN
0190603005530
UPC
190603005530
Semi baffle filter
Hush system
Led light
CFM reduction system
