PRODUCT DESCRIPTION
Specifications
Manufacturer Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
288.00
NET WEIGHT (kg)
145.15
CARTON LENGHT (mm)
819.00
CARTON HEIGHT (mm)
670.00
CARTON WIDTH (mm)
2300.00
VOLUMEN (M3)
0.47
SHIPPING WEIGHT
127.87
NET WEIGHT
121.25
CARTON LENGHT
32.24
CARTON HEIGHT
26.38
CARTON WIDTH
90.55
COUNTRY OF MANUFACTURE
CN
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Panel Ready
Color
custom
Features
Sabbath & Holiday Mode, ECO Mode, Soft close crisper & pantry drawers,Ultra Quiet operation, True Flush Install - 3D door adjustment, Cool Day LED interior light side walls & ceiling
WIDTH (IN)
30"
WIDTH (CM)
76.20
db (max)
43.00
ELECTRIC (VOLTS)
115V/ 220-240 V
AMPERAGE
2.0A
HERTZ
50-60
WATTS
551 W
LIGHTING
LED 6500K 300 lumens, 100 lumen for Freezer.
BULB TYPE
LED
BULB INCLUDED
YES
CONTROL TYPE
Electronic Soft-Touch Digital Black Glass display
Cooling Type
R600A
Defrost type
No Frost
Handle Color
Inox
REFRIGERANT
R600a
REMOTE CONTROL
NO
POWER SOURCE
Power Cord
OUTDOOR USE
No
INSTALLATION TYPE
Built-In, Bottom Mount
PANEL READY
Yes
ADJUSTBALE SHELVES
YES
REMOVABLE SHELVES
YES
Number of Cooling Zones
2.00
Number Of Shelves
3.00
DRAWERS
3 Humidity control Drawer + 1 Chiller Adjustable Temp Drawer
Shelf Material
Spill-Proof Glass
Door Storage
3 Height adjustable Bins
Door Features
#N/A
Storage Features
3 glass shelves and 3 soft close drawers
Reversible Door
YES
Door Swing
Reversible
Glass Doors
NO
Solid Doors
Panel ready/Stainless Steel Kit
Door Alarm
YES
Door Lock
NO
SABBATH MODE
YES
SMART HOME
NO
Humidity Control
Yes
Temperature (Min)
35(degree)F
Temperature (Max)
46(degree)F
Temperature Display
YES
Zone 1 Temp
NA
Chiller drawer Temp
30(degree)F (-1(degree)C) to 41(degree)F(5(degree)C)
Zone 2 Temp
NA
Freezer Temp
+5(degree)F to -11(degree)F
Volume
16 cu ft (453L)
CuFt
16.00
FRIDGE CAPACITY
11.50
FREEZER CAPACITY
4.50
ICE MAKER
YES
Total Capacity
NA
Bottle Capacity (750 ml /25 oz.)
NA
Bottle Capacity (12 oz.)
NA
Can Capacity (12 oz.)
NA
DIMENSIONS
73.66 X 58.42 X 210.82
DIMENSIONS inches
29 /16 x 23 /16 x 83 /4
Width
29 /16
Height
83 /4
Depth
23 /16
Counter Depth
23 /16
Depth with Door Open
55 /16
Depth with Handles
27 5/4
Depth without Door
22 19/32
Depth without Handles
23 5/4
Leveling legs
YES
Cutout
30 x 25 x 84
Cutout Depth
30"
Cutout Height
25"
Cutout Width
84"
Open Door Alarm
NA
Concealed hinge
NA
EPC technology
NA
High efficiency carbon filters
NA
Articulated hinge2
YES
Quiet operation
YES
Panel ready3
YES
GTIN
00190603007114
EAN
0190603007114
UPC
190603007114
