PRODUCT DESCRIPTION
Specifications
Width
30 , 36 , 42 , 48
Sones
Min 7 Max 8.2
Extraction capacity
600 CFM / 1200 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
45.40
NET WEIGHT (kg)
39.40
CARTON LENGHT (mm)
1046.00
CARTON HEIGHT (mm)
625.00
CARTON WIDTH (mm)
764.00
VOLUMEN (M3)
0.50
SHIPPING WEIGHT
100.09
NET WEIGHT
86.86
CARTON LENGHT
41.18
CARTON HEIGHT
24.61
CARTON WIDTH
30.08
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Vented
HOODS FEATURES
Hush system, Heat guard, Grease collectors, Professional performance, Seamless look
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
2040.00
CFM (MAX)
1200.00
db (min)
36.00
db (max)
56.00
SONES
1.7 - 8.5
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 8"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
8"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
7,6 A
HERTZ
60.00
WATTS
913.00
LIGHTING
Premium LED 2 x 6.5 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
6.50
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
Yes w/kit
DIMENSIONS
91 x 64 x 46
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
18"
Maximum Overall Height - Top to Bottom
22 5/16
Overall Height - Top to Bottom
18"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
25"
Hood Height
18"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
KIT0192765 + KIT0192763+KIT0204547
CHIMNEY EXTENSION NUMBER
KIT02158/KIT02161
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
KIT0185099
BACKSPLASH KIT
KIT0142867
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
KIT0179549
EXTERNAL BLOWER SHELL KIT
KIT0179547
HEAT LAMPS
KIT0155107
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
CERTIFICADO NOM
NA
DIMENSIONS inches
36" x 25" x 18"
Prop65 Disclosure
YES
GTIN
00190603001914
EAN
0190603001914
UPC
190603001914
Hush system
Heat guard
Grease collectors
Professional performance
Seamless look
