PRODUCT DESCRIPTION
Specifications
Width
20
Sones
7
Extraction capacity
355 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
16.40
NET WEIGHT (kg)
12.65
CARTON LENGHT (mm)
600.00
CARTON HEIGHT (mm)
600.00
CARTON WIDTH (mm)
654.00
VOLUMEN (M3)
0.23
SHIPPING WEIGHT
36.16
NET WEIGHT
27.89
CARTON LENGHT
23.62
CARTON HEIGHT
23.62
CARTON WIDTH
25.75
COUNTRY OF MANUFACTURE
IT
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Non-Vented
HOODS FEATURES
Long Life Filter, Perimeter aspiration, Maintenance alarm, Led Light
WIDTH (IN)
20
WIDTH (CM)
51.00
AIRFLOW (M3/H)
603.00
CFM (MAX)
350.00
db (min)
31.70
db (max)
54.00
SONES
1.3 - 6.0
EXHAUST VERSION
Recirculating Only
EXHAUST SIZE
NA
DUCT SHAPE
NA
EXHAUST LOCATION
NA
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
NA
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3.8 A
HERTZ
60.00
WATTS
460.00
LIGHTING
LED 3 x 2.5 ww 4000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
3.00
BULB WATTS
2.50
KELVINS
4000.00
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Push Buttons with Perimetral Light
SPEED CONTROL
YES
NUMBER OF SPEEDS
3 + booster
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
No
DIMENSIONS
51 x 51 x 53
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
21 1/ "
Maximum Overall Height - Top to Bottom
51 3/
Overall Height - Top to Bottom
21 -51
Overall Width - Side to Side2
20 1/4
Overall Depth - Front to Back
20 1/4
Hood Height
15 1/2"
Minimum Compatible Ceiling Height
6'10"
Maximum Compatible Ceiling Height
11'8
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENSION NUMBER
NA
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
KIT0121394
HIGH CEILING EXTENSION KIT
KIT01921
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
YES
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
Activo
DIMENSIONS inches
20 1/4 x 20 1/4 x 15 1/2"
Prop65 Disclosure
YES
GTIN
00190603002232
EAN
0190603002232
UPC
190603002232
Long Life Filter
Perimeter aspiration
Maintenance alarm
Led Light
