Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
33.80
CARTON LENGHT (mm)
781.00
CARTON HEIGHT (mm)
413.00
CARTON WIDTH (mm)
1074.00
SHIPPING WEIGHT (lb)
74.52
COUNTRY OF MANUFACTURE
PL
INTENDED APPROVED USE
Residential use
Type of Ventilation
Convertible
HOODS FEATURES
Long life filter, Special Materials, Led Light, Maintenance alarm, Total Integration, Comfort silence
EXHAUST VERSION
Convertible with Kit
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
Strip LED 1 x 7 W 3500 K
GREASE FILTER TYPE
Sophisticated Black Iron Grates + 6 Layer Aluminium Mesh Filter
DISHWASHERSAFE FILTER
YES
BLOWER TYPE
Interior Unit
CONTROL TYPE
Sensitive Touch Control with Backlight
NUMBER OF SPEEDS
3 + booster
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
33 x 32 x 81-124
DIMENSIONS_x000D_ (INCH)
13" x 12 3/5 x 32-49"
Minimum Overall Height - Top to Bottom
13"
Maximum Overall Height - Top to Bottom
49"
Overall Height - Top to Bottom
32 -49
Overall Width - Side to Side2
13"
Overall Depth - Front to Back
15
Min - Max Compatible Ceiling Height (Cover electronic cooking)
7'3"
Min - Max Compatible Ceiling Height ( Cover gas cooking)
10'1"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
12"
Chimney Depth - Front to Back
12"
Chimney Height - Top to Bottom
49
COMFORT SILENCE America
4.00
LONG LIFE FILTER America
2.00
TOTAL INTEGRATION America
5.00
Long Life Recirculating Carbon Filter
CFC0141725AUL
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600/1200 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 " round deflector
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation 4 round carbon filters
NA
Recirculation(8 round deflector)
NA
Long Chimney Ext/Chimney extension
-
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension_x000D_ (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
NA
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
INLINE BLOWER (1200CFM)
NA
EXTERNAL BLOWER (1200 CFM)
NA
INLINE BLOWER SHELL KIT (600 CFM)
NA
INLINE BLOWER SHELL KIT
NA
EXTERNAL BLOWER SHELL KIT
NA
HIGH CEILING EXTENSION KIT
NA
Duct cover extension 6
NA
Duct cover extension 18
NA
ELECTRONIC CFM REDUCTION BYPASS
NA
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
YES
