Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
Fracci n arancelaria
8414600100.00
SHIPPING WEIGHT (kg)
57.00
CARTON LENGHT (mm)
1010.50
CARTON HEIGHT (mm)
409.00
SHIPPING WEIGHT (lb)
125.66
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Type of Ventilation
Non-Vented
HOODS FEATURES
Perimeter aspiration, Top performance
EXHAUST VERSION
Ducted Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Rotating Disc
NUMBER OF SPEEDS
3 + booster
RECIRCULATION KIT NEEDED
NO
DIMENSIONS (CM)
76 x 32 x 35
DIMENSIONS (INCH)
36" x 12 1/2 x 14"
Overall Height - Top to Bottom
14"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
12 1/2
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
NA
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 round carbon filters
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation (1200 CFM) 4 round carbon filters
NA
Recirculation (1200 CFM) (8 round deflector)
NA
Long Chimney Ext/Chimney extension
NA
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
-
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
CFM REDUCTION KIT
KIT02748
INLINE BLOWER SHELL KIT (600 CFM)
-
INLINE BLOWER SHELL KIT (1200 CFM)
NA
EXTERNAL BLOWER SHELL KIT
-
HIGH CEILING EXTENSION KIT
-
Duct cover extension 6
NA
Duct cover extension 18
NA
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
DOWNDRAFT
FITLER INDICATOR LIGHT
NO
