PRODUCT DESCRIPTION
Features
Extra Large Oven Capacity
Cook more at once with our extra large, 5.3 cu. ft. capacity oven.
Fan Convection
Get faster, more even multi-rack baking results with Fan Convection.
Custom Broil Temp Setting
Allows you to choose the specific broil temperature you want, ranging anywhere between 400 - 550 degrees.
Self Clean Oven
Self clean options available in convenient 2, 3 and 4-hour cycles.
Frigidaire(R) Fit Promise
Premium Touch Screen Control Panel
Features a responsive 4.3 inch, full color, capacitive touch digital control panel.
Convenient Cook Time Setting
Allows you to program the amount of time you want your oven to cook and then turn off.
Specifications
Bake
Yes
Bake Time
Yes
Broil
Yes
Cancel
Yes
Clock
Yes
Convection Bake
Yes
Cook Time
Yes
Delay Start
Yes
Keep Warm
Yes
Kitchen Timer
Yes
Light
Yes
Off
Yes
Oven Light
Yes
Preheat
Yes
Self Clean
Yes
Start
Yes
Temperature Display
Yes
Timer On / Off
Yes
Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
Yes
Program Fahrenheit or Celsius
Yes
Silent Control Panel
Yes
Bake Element
2500 Watts
Bake Element Pass
8
Bake Element Type
Hidden
Broil Element
4000 Watts
Broil Element Pass
6
Broil System
Yes
Cleaning System
Yes
Convection
Yes
Convection Type
Fan
Number of Convection Fans
1
Number of Rack Positions
6
Oven Interior Color
Midnight Black
Oven Light Quantity
1
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Embossed
Rack Type 1
Flat
Rack Type 1 Quantity
2
Control Lock
Yes
Sabbath Mode
Yes
Display Interface Color
White
Display Light Color
White
Display Type
Capacitive Touch
Handle Color
Black
Height
28"
Width
29 7/8"
Depth
25 3/16"
Depth With Door 90(degree) Open
48 3/16"
Depth With Handle
27 3/5"
Oven Interior Height
18 1/8"
Oven Interior Width
25 1/5"
Oven Interior Depth
19 7/8"
Minimum Cutout Height
26 3/4"
Minimum Cutout Width
28 1/2"
Maximum Cutout Height
28"
Maximum Cutout Width
29"
Oven Capacity
5.3 Cu. Ft.
Amps @ 240 Volts
20 Amps
Connected Load @ 240V
3.7 kW
Minimum Circuit Required
20 Amps
Voltage Rating
240 V
Frigidaire Fit Promise
Yes
Product Weight
130 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Power Supply Connection Location
Top Left
ADA Compliant
Yes
CSA Listed
Yes
RoHS
Yes
UL Listed
Yes
Optional Trim Kit Part Number
WOMC3TRIMSS, WOMC3TRIMDSS, WOMC3TRIMBLK, WOMC3TRIMWHT
Product Line
Single Wall Oven
Power Type
Electric 240v
Size
30"
Installation Type
Built-In
Factory
Springfield
Color
Black
GTIN
00012505514975
EAN
0012505514975
UPC
012505514975
Fan Convection
Self Clean Oven
Frigidaire(R) Fit Promise
Premium Touch Screen Control Panel
Extra Large Oven Capacity
Custom Broil Temp Setting
Convenient Cook Time Setting
Keep Warm Setting
