PRODUCT DESCRIPTION
Specifications
Cooking Surface Type
Smooth
Hot-Surface Indicator Light
Yes
Right Front Element Burner Size
6"
Right Rear Element Burner Size (Small)
9"
Right Rear Element Burner Size (Large)
12"
Left Front Element Burner Size
6"
Left Rear Element Burner Size
9"
Right Front Element Burner
1200 Watts
Right Rear Element Burner (Small)
1800 Watts
Right Rear Element Burner (Large)
3000 Watts
Left Front Element Burner
1200 Watts
Left Rear Element Burner
3200 Watts
Control Location
Front
Backlit Knobs
Yes
Height
2 5/8"
Width
30 5/8"
Depth
21 3/8"
Cutout Height
5"
Minimum Cutout Width
28 1/2"
Minimum Cutout Depth
19 5/8"
Maximum Cutout Width
29 7/8"
Maximum Cutout Depth
20 1/2"
Amps @ 240 Volts
35.8 Amps
Connected Load @ 240V
8.6 kW
Minimum Circuit Required
40 Amps
Voltage Rating
240 V
Frigidaire Fit Promise
Yes
Product Weight
31 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
AB-1200
Information available at frigidaire.com/en/ab1200
Installed Over a Wall Oven
Yes
Power Supply Connection Location
Right Center
ADA Compliant
Yes
CSA Listed
Yes
UL Listed
Yes
Product Line
Electric Cooktop
Power Type
Electric 240v
Size
30"
Installation Type
Built-In
Factory
Rayong
Color
Stainless Steel
GTIN
00810143401493
EAN
0810143401493
UPC
810143401493
