Built-in WiFi powered by SmartHQ(TM) True Built In Design The ultimate fit & finish for more usable space and the best in built-in installation. Sleeve and chassis are perfectly integrated, creating a seamless fit without leaks or gaps Premium Guard Seacoast Protection Premium Seacoast Protection on heat/cool models has special coatings and double coats of paint on key components including coils, base pan, compressor and stainless screws Premium Finish Bright, clean color & a decorative metallic silver accent encasing the air discharge louver, provide an overall sleek appearance Electronic Cap Touch Controls Controls offer a high-end and smooth to-the-touch panel Large LCD Auto-Dimming Display Intuitive & large white LCD display can be easily seen from anywhere in the room. Convenient Auto-Dimming feature provides ambient lighting during the night Slim Room Front A slim room front provides more usable space in the room. It's the sleekest design in the industry ECO Mode Innovative mode where the fan cycles off during cooling intervals, creating energy savings while keeping the room comfortable Dry Mode Designed for humid environments, it helps provide a dryer & more comfortable atmosphere with room-air dehumidification Auto Mode Automatically select heating or cooling mode and fan speed to maintain the current temperature setpoint. It monitors the room temperature for optimal comfort 3-Speed Fan Select High, Medium, Low or Auto Setting to achieve the best in air comfort & ultimate flexibility. Available on heat-cool models 6-Way Directional Airflow Direct where the air flows with up to 6 directional vents-cooling and/or heating the areas of the room that need it the most Washable Filter Easy to remove and rinse clean, the filter helps remove dust and other particles from transmitting in the air-providing a cleaner environment Remote Control Included Slim, intuitive and easy to use, the remote control enables adjusting temperatures and settings conveniently from anywhere in the room Quiet Performance Designed & engineered by GE Appliances for ultra-quiet comfort
Specifications
capacity
3 items
Cooling BTUH (MAX)
8000 Btu
Heating - Electric - BTUH - AHAM - 1R
4200
Dehumidification (pts./hr.)
1.9
appearance
2 items
Installation
Wall Mounted
Color Appearance
Soft Gray
warranty
3 items
Warranty Notes
See written warranty for full details
Labor Warranty
Limited 2-year entire appliance Limited 5-year sealed system
Parts Warranty
Limited 2-year entire appliance
power / ratings
8 items
Hertz
60
Volts/Hertz
115V; 60Hz
Cooling - Rated Cooling Amps AHAM
7.4
Cooling - Watts
820
Voltage/Hertz/Phase
115/60/1
CEER
9.6
Voltage (MAX)
115 V
Heating - Electric - Heater Amps
11.0
accessories
1 item
Wall Case
RAB46/47/48/26 Required At Additional Cost
weights & dimensions
13 items
Overall Width
26 in
Approximate Shipping Weight
78 lb
Min./Max. Window Opening Width (in.)
26.125 in
Depth to Louvers
5 in
Overall Height (Excludes Sleeve)
14.875 in
Overall Height
15.625 in
Overall Depth (Excludes Sleeve)
19.90625 in
Minimum Window Opening Height (in.)
15.75 in
Cutout Width (in)
26.125 in
Overall Depth
21.8125 in
Overall Width (Excludes Sleeve)
24.8125 in
Cutout Height (in)
15.75 in
Net Weight
78 lb
features
23 items
Louver Style
6-Way
Control Type
Electronic
Fan Speed Selections
3 Cooling 3 Fan Only
Optional Grill
RAG13/RAG13A/RAG14E
Refrigerant Type
R32
Product Type
Built-In
Air Discharge
Over / Under
Filter Type
Rigid Frame Tilt-Out Washable
Style
Thru-Wall
Chassis Type
Slide-In
Plug Type
Parallel/Right Angle LCDI
Heating - Electric - Input Watts
1250
Connected Capabilities
Amazon Alexa Google Home
WiFi Connect
Built-In
Remote Control
Yes
Thermostat Type
Electronic Digital
Temperature Range
60->85 F
Airflow (cfm) Roomside
265/225
Cord Length
75"
Rotary Compressor
Yes
Outdoor Vent / Exhaust
Yes
Unit Type
Heat / Cool Unit
Room Air Conditioner Features
Batteries Included Improved Corrosion Package Remote Control Smart Fan Switch
