GET READY FOR INSTALLATION
PACKAGES
PRODUCT DESCRIPTION
Specifications
Parts
1 Year
Labor
1 Year
Overall Depth
24 in
Overall Width
23.75 in
Overall Height
33.375 in
Height w/ Legs Retracted - Minimum Height
33.375 in
Cabinet Width
24 in
Net Weight
54 lb
Approximate Shipping Weight
68 lb
Overall Depth with Handle
25.875 in
Height w/Legs Extended - Maximum Height
34.625 in
Depth with Door Open
27.5 in
Depth Without Handle
24 in
Cutout Height (in)
33.5
Cutout Width (in)
24
Cutout Depth (in)
24
Wash System
2-Level
Tub Type
Tall Tub
Leveling System
4 Leveling Legs
OU Certified
No
Number of Place Settings
14
Dishwasher Options
Sabbath Mode
Latch
Center Pull
Number of Options
4
Style
Built-In Top Control
Water Filtration System
100% Filtration with Piranha Hard Food Disposer and Removable Filter
Rack Features
1 Utility Shelf with Stem Safe
Dishwasher Cycles
1 Hour Wash
Rack Color
Silver
Dispenser
Detergent
WiFi Connect
Optional (Requires part no. PBX23W00Y1)
Control Type
4 Touchpads
Dishwasher Drying Features
Calrod Heater
Wash Arms
Lower
Wash System Features
Active Flood Protect
Exterior Style
Traditional
Active Flood Protection
Active Flood Protect
Product Type
Built-In
Upper Rack
Removable
Dishwasher Control Features
1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators
Number of Cycles
4
Tub and Door Liner
Gray Plastic
Sabbath Mode
Yes
Showroom Power Mode
Yes
Handle
Towel Bar
Installation
Built-Up Floor Capable
Handle Color
Stainless Steel
Door Style
Flat Door
Door Appearance
Full-length flat door
Color Appearance
Stainless Steel
Energy Consumption (kWh/year)
240
Power Connection
Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
Electrical Requirements
120V ; 60Hz ; 7.1A
Calrod Heater Watts
800/500
Hertz
60
Watts
792
Labor Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 1-year entire appliance
Quiet Package
55 dBA
Width
23.75 in.
Height
33.38 in.
Length
24 in.
Weight
54 lbs.
Number of Boxes
1
Shipping Width
28.75 in.
Shipping Height
38.38 in.
Shipping Length
29 in.
Shipping Weight
94 lbs.
Total of Shipping Weight
94 lbs.
Source
Calculation
Cubic Feet Measurement
11.01 ft³
Dimensional Weight
136.86 lbs.
Total of Cubes
11.01 ft³
Total of Dimensional Weight
136.86 lbs.
High Wash Performance
Choose Your Cycle
Dishwasher with Upper & Lower Rack Capacity
Quiet 55 dBA Dishwasher
Extra Large Capacity
Heavy-Duty Plastic Interior Dishwasher
ENERGY STAR Dishwasher
Top or Side Mount Installation Brackets
Built-Up Floor Capable
Reliable Performance
Dry Boost
Steam + Sani
Water Leak Sensor
Hard Food Disposer
ENERGY STAR® Dishwasher
Dry Boost™
Wash System
2-Level
Tub Type
Tall Tub
Leveling System
4 Leveling Legs
OU Certified
No
Number of Place Settings
14
Dishwasher Options
Dry Boost(TM) (High) (BR)Dry Boost(TM) (Normal) (BR)Lock Controls (BR)Sabbath Mode (BR)Start/Reset (BR)Steam + Sani (Certified to NSF Standard 184) (BR)Wash TempBoost
Latch
Center Pull
Number of Options
4
Style
Built-In Top Control
Water Filtration System
100% Filtration with Piranha Hard Food Disposer and Removable Filter
Rack Features
1 Piece Silverware Basket (BR)1 Utility Shelf with Stem Safe (BR)Chop stick slots
Dishwasher Cycles
1 Hour Wash (BR)Heavy Wash (BR)Normal Wash (BR)Rinse
Rack Color
Silver
Dispenser
Detergent (BR)Rinse Aid
WiFi Connect
Optional (Requires part no. PBX23W00Y1)
Control Type
4 Touchpads (BR)Fully Integrated Inlaid Electronic Buttons (BR)Top Controls
Dishwasher Drying Features
Calrod Heater (BR)Dry Boost(TM)
Wash Arms
Lower (BR)Middle
Wash System Features
Active Flood Protect (BR)Automatic HotStart (BR)Automatic Temperature Control (BR)Fill Level Pressure Sensor (BR)Piranha(TM) Hard Food Disposer with removable filter
Exterior Style
Traditional
Active Flood Protection
Active Flood Protect
Product Type
Built-In
Upper Rack
PVC (BR)Removable (BR)Standard
Dishwasher Control Features
1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators (BR)Last Cycle Memory
Number of Cycles
4
Tub and Door Liner
Gray Plastic
Sabbath Mode
Yes
Showroom Power Mode
Yes
UPC
084691863526
GTIN
00084691863526
EAN
0084691863526
Handle
Towel Bar
Installation
Built-Up Floor Capable (BR)Side Installation or Top Installation Included
Handle Color
Stainless Steel
Door Style
Flat Door
Door Appearance
Full-length flat door
Color Appearance
Stainless Steel
Power Connection
Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
Energy Consumption (kWh/year)
240
Hertz
60
Electrical Requirements
120V ; 60Hz ; 7.1A
Watts
792
Calrod Heater Watts
800/500
Labor Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 1-year entire appliance
Quiet Package
55 dBA
Height w/ Legs Retracted - Minimum Height
33.375 in
Cutout Height (in)
33.5
Cutout Width (in)
24
Overall Depth
24 in
Cabinet Width
24 in
Net Weight
54 lb
Overall Width
23.75 in
Depth Without Handle
24 in
Approximate Shipping Weight
68 lb
Overall Height
33.375 in
Overall Depth with Handle
25.875 in
Cutout Depth (in)
24
Height w/Legs Extended - Maximum Height
34.625 in
Depth with Door Open
27.5 in
