PRODUCT DESCRIPTION
Features
Lowboy
Make the most of tight spaces with a water heater that fits where height is a concern
Quick Recovery
Two 5500W heating elements quickly increase water temperature for hot water when you need it
Household Size
Provide hot water for the whole family of 1 to 3 persons
Inlet Tube
Replenishes water from the bottom of the tank to maximize hot water delivery
Adjustable Thermostat
Change temperature to your desired setting
Easy Set Up
Replace your old water heater quickly and easily using standard water and electrical connections
Anode Rod
Durable design offers long-lasting protection against corrosion
Drain Valve
Rust-proof construction can be counted on to provide long-lasting service
Specifications
Unit Capacity
28 Gallons
Color Appearance
Gray
Integrated Energy Factor
0.93
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
58 Gallons
Voltage (MAX)
240 V
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
Warranty Notes
See written warranty for full details
Parts Warranty
8-year limited
Labor Warranty
1-year limited
Product Height (to top of water inlet/outlet connections)
24.875 in
Approximate Shipping Weight
114 lb
Overall Width
24 in
Overall Height
31.25 in
Product Height (to top of unit)
31.25 in
Net Weight
105 lb
Product Diameter
24 in
Overall Depth
24 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Rated Capacity
26 gal
Height Description
Low Boy with Side Port
Fuel Type
Electric
Configuration
Lowboy
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
26
Drain Valve Type
Plastic
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Temperature Setting Factory Default
120(degree) F
Product Type
Electric Thermostat
Family Size
1-3 People
Water Connection Location
Side
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150(degree) F Range
Insulation Thickness
2.75 in
GTIN
00084691846130
EAN
0084691846130
UPC
084691846130
