PRODUCT DESCRIPTION
Features
Serpentine system
Water is heated and stored directly in the solar collector, making hot water available as soon as it's heated by the sun
Storage tank
Integrated into the solar collector, the tank maintains hot water temperatures even if the sun isn't shining. The pipes in the tank have a 38-gallon capacity rating, enough to satisfy the needs of the home
Innovative frame
Aluminum profiles and rigid foam insulation at the sides and rear of the solar collector provide total durability
One-of-a-kind design for versatile installation
Accommodate any roof style with a unit that's easy to set up
Internal tank coating
Resilient internal coating offers maximum corrosion resistance and trouble-free performance
Clear heat insulation
Totally transparent insulation delivers maximum heat retention
Solar glass
Water is efficiently heated in the integrated storage tank the moment sunlight hits the solar glass
Specifications
Unit Capacity
38 Gallons
Color Appearance
Gray
Parts Warranty
10-year limited
Weight (with mount, with water) (lb)
444
Approximate Shipping Weight
128 lb
Collector outer dimensions (inches)
86x33x8
Net Weight
114.6 lb
Weight (with mount, no water) (lb)
125
Max height, mount 45/30 (inches)
28/22
Net Collector Area (ft )
17
Gross area (ft)
19
Max. operating pressure (psi)
60
Heat transfer medium
Water
Volume hot water storage tank (gal)
38
Thermal insulation - storage tank (inches)
1.2
Product Type
Solar
Collector Inclination Angle from horizontal (degrees)
10 to 75
Cold/hot water connections (inches)
3/4 MNPT
GTIN
00084691845966
EAN
0084691845966
UPC
084691845966
