PRODUCT DESCRIPTION
Features
Fresh food multi-level drawers
Provide the ideal environment for storing your fruits and vegetables
Glass freezer shelves
Enjoy a high-end appearance with secure storage for a variety of items
Advanced water filtration
Counter-depth design
Offers a built-in look by fitting nearly flush with surrounding cabinetry
Specifications
Fresh Food Capacity
14.08 cu ft
Total Capacity (cubic feet)
21.9 cu ft
Freezer Capacity
7.79 cu ft
Dispenser Color
Color-Matched
Case Color
White
Exterior Design
Rounded Doors
Door Stops
Yes
Textured Steel Case
Case Only
Handle Color
White
Counter-Depth Design
true
Door Swing
Side-by-Side
Color Appearance
White
Handle
High-Gloss
Door Appearance
Gloss
Energy Consumption (kWh/year)
669
Volts/Hertz/Amps
120v; 60Hz; 15A
Electrical Requirements
120V
Hertz
60
Watts
330
Warranty Notes
See written warranty for full details
Labor Warranty
Limited 1-year entire appliance
Parts Warranty
Limited 1-year entire appliance
Cabinet Liner
ABS
Overall Depth
29.5 in
Height to Top of Hinge
69.25 in
Net Weight
340 lb
Overall Width
35.75 in
Back Air Clearances
2 in
Width w/Door Open 90 Degrees Less Handle
36.375 in
Approximate Shipping Weight
360 lb
Depth with Door Open 90(degree)
46 in
Width w/Door Open 90 Degrees Incl. Handle
41.375 in
Case Depth Without Door
23.875 in
Top Air Clearances
1 in
Side Air Clearances
0.125 in
Depth Without Handle
27 in
Height to Top of Case
68.75 in
Overall Height
69.25 in
Overall Depth with Handle
29.5 in
Temperature Management Features
4 Electronic Sensors Short Air Tower
Dispenser Features
Child Lock Door Alarm LED Dispenser Light Water Filter Indicator Light
Control Type
Actual Temperature Display Upfront Electronic Touch Temperature Controls
Icemaker
Factory-Installed
Freezer Cabinet Shelves
1 Sweet Spot Shelf 1 Wire Fixed 2 Glass Adjustable 4 Total
WiFi Connect
Optional (Requires part no. PBX23W00Y1)
Performance Features
Easily Removable Door Gaskets Never Clean Condenser
Filter Location
Upper right corner
Door Alarm
Yes
Freezer Storage Baskets
1 Wire
Freezer Door Shelves
5 Fixed 5 Total
Defrost Type
Frost Guard
Fresh Food Door Features
Dairy Compartment
Leveling System
2 Point Front Adjustable
Fresh Food Cabinet Shelves
3 Adjustable 3 Slide-Out 4 Spill Proof 4 Total Glass
Middle Drawer
Adjustable Humidity
Fresh Food Door Bins
2 Adjustable with Gallon Storage 2 Fixed 4 Total
Freezer Features
Ice Storage Bin Interior Lighting - LED
Exterior Style
Counter-Depth
Temperature Display
External Digital
Fresh Food Features
Integrated Shelf Support System Interior Lighting - LED Interior Storage Drawers
Refrigerant Type
R600a
Door Liner
ABS
Dispenser
Integrated with Cubes, Crushed Ice & Chilled Water
Fresh Food Cabinet Drawers
2-Stack drawer system Multi-Level Drawers
Water Filtration
GE Water Filtration 6 Month MWF XWF (on select models manufactured after June 2018)
Product Type
Counter Depth Refrigerator Side-by-Side Refrigerator
Counter-depth design
LED lighting
Integrated shelf support system
Adjustable slide-out, spillproof glass shelves
Adjustable clear door bins
Fresh food multi-level drawers
Glass freezer shelves
Advanced water filtration
Cabinet Liner
ABS
GTIN
00084691814023
EAN
0084691814023
UPC
084691814023
Overall Depth
29.5 in
Height to Top of Hinge
69.25 in
Net Weight
340 lb
Overall Width
35.75 in
Back Air Clearances
2 in
Width w/Door Open 90 Degrees Less Handle
36.375 in
Approximate Shipping Weight
360 lb
Depth with Door Open 90(degree)
46 in
Width w/Door Open 90 Degrees Incl. Handle
41.375 in
Case Depth Without Door
23.875 in
Top Air Clearances
1 in
Side Air Clearances
0.125 in
Depth Without Handle
27 in
Height to Top of Case
68.75 in
Overall Height
69.25 in
