PRODUCT DESCRIPTION
Features
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Specifications
Insert ventilation extractor
Yes
Color
Stainless steel
Recirculated mode
Can be retrofitted
Recirculation conversion kit (order separately)
DUU 151
OdorFree charcoal filter (order separately)
DKF 19-P
Electronic controls
Yes
Operation
Light-touch switches with LEDs
Power levels (number excl. Intensive)
3
Booster levels
1
CleanCover
Yes
Easy-to-clean CleanCover hood liner
•
Easy-to-clean canopy interior - CleanCover
Yes
Number of dishwasher-safe stainless-steel grease filters
1
Number of dishwasher-safe stainless steel grease filters (10-ply)
1
LED ClearView lighting
Yes
Number x W
2 x 3 W
Light intensity in Lx
350 lx
Color temperature in K
3000 Kelvin
Dual-action blower
Yes
AC motor
Yes
Maximum air throughput in cfm according to HVI
395
Air throughput
Values upon request
Air throughput in booster level 1 (cfm) (m /h)
482.64 (820)
Air throughput in Booster level 1 (m /h)
482.64 (820)
Air throughput with Booster level 1 (m /h) according to EN 61591
482.64 (820)
Air throughput in CFM in Booster
395
Safety shut-off
Yes
Canopy width in in. (mm)
23 (584)
Canopy height in in. (mm)
2 1/2 (63)
Depth of hood canopy in in. (mm)
11 3/4 (297)
Minimum distance above electric cooktops in in. (mm)
24 1/8 (610)
Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
25 (11.0)
Length of electrical wire in ft. (m)
4 (1.5)
Standard plug fitted
Yes
Total connected load in kW
0.356
Voltage in V
120
Fuse rating in A
15
Frequency in Hz
60
Number of phases
1
Minimum height above electric cooktops in mm
24 1/8 (610)
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Vent connection at top
Yes
Vent connection at top and rear
Yes
Diameter of vent connection in in. (mm)
6 (150)
Non-return flap
Yes
GTIN
04002515949887
EAN
4002515949887
EAN
4002515949887
Customized kitchen design - fully integrated in 23 (584) in (mm) width
Powerful - 482.64 (820) ft /min (m3/h) in Booster level
Efficient filtration- 10-ply stainless steel grease filters
Safe and easy to clean - Miele CleanCover
Safety information
Safety turn off
Stainless-steel grease filters (10-layer)
Miele CleanCover
