PRODUCT DESCRIPTION
Features
Delayed shutdown
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Specifications
Insert ventilation extractor
Yes
Color
Stainless steel
Recirculated mode
Can be retrofitted
Recirculation conversion kit (order separately)
DUU 151
OdorFree charcoal filter (order separately)
DKF 15-P
Miele@home
Yes
Automatic function Con@ctivity
Yes
Electronic controls
Yes
Operation
Light-touch switches with LEDs
Power levels (number excl. Intensive)
3
Booster levels
1
Programmable Intensive switch-off
Yes
Delayed shutdown for 5 or 15 minutes
Yes
Grease filter saturation indicator
Yes
Active charcoal filter saturation indicator
Yes
CleanCover
Yes
Easy-to-clean CleanCover hood liner
•
Easy-to-clean canopy interior - CleanCover
Yes
Number of dishwasher-safe stainless-steel grease filters
3
Number of dishwasher-safe stainless steel grease filters (10-ply)
3
LED ClearView lighting
Yes
Number x W
4 x 3 W
Light intensity in Lx
520 lx
Color temperature in K
3000 Kelvin
Dual-action blower
Yes
AC motor
Yes
Maximum air throughput in cfm according to HVI
415
Air throughput
Values upon request
Air throughput in booster level 1 (cfm) (m /h)
500.29 (850)
Air throughput in Booster level 1 (m /min)
850
Air throughput in Booster level 1 (m /h)
500.29 (850)
Air throughput with Booster level 1 (m /h) according to EN 61591
500.29 (850)
Air throughput in CFM in Booster
415
Safety shut-off
Yes
Canopy width in in. (mm)
43 1/2 (1102)
Canopy height in in. (mm)
2 (50)
Depth of hood canopy in in. (mm)
15 7/8 (402)
Minimum distance above electric cooktops in in. (mm)
24 1/8 (610)
Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
32 (14.3)
Length of electrical wire in ft. (m)
2 (0.8)
Standard plug fitted
Yes
Total connected load in kW
0.362
Voltage in V
120
Fuse rating in A
15
Frequency in Hz
60
Number of phases
1
Minimum height above electric cooktops in mm
24 1/8 (610)
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Vent connection at top
Yes
Vent connection at top and rear
Yes
Diameter of vent connection in in. (mm)
6 (150)
Non-return flap
Yes
Communication module for Con@ctivity XKM 2000 DA
XKS 3000 Z
GTIN
04002516024699
EAN
4002516024699
EAN
4002516024699
Customized kitchen design - fully integrated in 43 1/2 (1102) in (mm) width
Unique user convenience - Con@ctivity
Powerful - 500.29 (850) ft /min (m3/h) in Booster level
Efficient filtration- 10-ply stainless steel grease filters
Safe and easy to clean - Miele CleanCover
Safety information
filter saturation indicator
Con@ctivity
Safety turn off
Delayed shutdown
Stainless-steel grease filters (10-layer)
Miele CleanCover
