PRODUCT DESCRIPTION
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes."
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
Features
Edge vented
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Delayed shutdown
Specifications
Insert ventilation extractor
•
Color
Stainless steel
Edge extraction
•
Recirculated mode
Exhaust air
Miele@home
•
Automatic function Con@ctivity
•
Electronic controls
•
Operation
Light-touch switches with LEDs
Power levels (number excl. Intensive)
3
Booster levels
1
Programmable Intensive switch-off
•
Delayed shutdown for 5 or 15 minutes
Grease filter saturation indicator
•
CleanCover
Easy-to-clean CleanCover hood liner
•
Number of dishwasher-safe stainless-steel grease filters
4
LED ClearView lighting
•
Number x W
3 x 4,5 W
Light intensity in Lx
700 lx
Color temperature in K
3500 Kelvin
Light dimmer function
•
Dual-action blower
•
AC motor
•
Maximum air throughput in cfm according to HVI
401
Air throughput
Values upon request
Safety shut-off
•
Canopy width in in. (mm)
46 1/2 (1180)
Canopy height in in. (mm)
2 1/2 (63)
Depth of hood canopy in in. (mm)
11 5/8 (293)
Minimum distance above electric cooktops in in. (mm)
24 1/8 (610)
Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
34 (15.0)
Length of electrical wire in ft. (m)
4 (1.5)
Standard plug fitted
•
Total connected load in kW
0.36
Voltage in V
120
Fuse rating in A
15
Frequency in Hz
60
Number of phases
1
Vent connection at top
•
Vent connection at top and rear
•
Diameter of vent connection in in. (mm)
6 (150)
Non-return flap
•
Communication module for Con@ctivity XKM 2000 DA
XKS 3000 Z
GTIN
04002516024439
EAN
4002516024439
Customized kitchen design - fully integrated in 46 1/2 (1180) in (mm) width
Unique user convenience - Con@ctivity
Energy-efficient and quiet
Elegant and efficient - edge vented panel
filter saturation indicator
Stainless-steel grease filters (10-layer)
Edge vented
Safety turn off
Miele CleanCover
Delayed shutdown
Con@ctivity
