PRODUCT DESCRIPTION
Features
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Edge vented
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Delayed shutdown
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Specifications
Ceiling fan
Color
Stainless steel
Edge extraction
Recirculated mode
Can be retrofitted
Recirculation conversion kit (order separately)
DUU 2900-900
Miele@home
Automatic function Con@ctivity
Electronic controls
Operation
Light-touch switches with LEDs
Miele@mobile app
Power levels (number excl. Intensive)
3
Booster levels
1
Programmable Intensive switch-off
Delayed shutdown for 5 or 15 minutes
Grease filter saturation indicator
Active charcoal filter saturation indicator
CleanCover
Easy-to-clean CleanCover hood liner
Number of dishwasher-safe stainless-steel grease filters
2
LED ClearView lighting
Number x W
4 x 3 W
Light intensity in Lx
600 lx
Color temperature in K
3500 Kelvin
Light dimmer function
Dual-action blower
AC motor
Maximum air throughput in cfm according to HVI
401
Air throughput
Values upon request
Safety shut-off
Overall hood height for vented mode and external in inches (mm)
13 3/8 (339)
Overall hood height for recirculation and external in inches (mm)
13 3/8 (339)
Overall min. height for vented and external in in. (mm)
13 3/8 (339)
Overall max. height for vented and external in in. (mm)
13 3/8 (339)
Overall min. height for recirculation in in. (mm)
13 3/8 (339)
Overall max. height for recirculation in in. (mm)
13 3/8 (339)
Canopy width in in. (mm)
43 3/8 (1100)
Canopy height in in. (mm)
13 1/2 (342)
Depth of hood canopy in in. (mm)
27 5/8 (700)
Minimum distance above electric cooktops in in. (mm)
24 1/8 (610)
Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
47 (21.0)
Length of electrical wire in ft. (m)
2 (0.8)
Standard plug fitted
Total connected load in kW
0.362
Voltage in V
120
Fuse rating in A
15
Frequency in Hz
60
Number of phases
1
Vent connection at top
Vent connection on side
Vent connection at top, rear, and side
Diameter of vent connection in in. (mm)
6 (150)
Installation template
Combination with WiFi-enabled Miele cooktop
required
Non-return flap
Communication module for Con@ctivity XKM 2000 DA
XKS 3000 Z
GTIN
04002516064947
EAN
4002516064947
Elegant design - harmonious in the kitchen environment
Unique user convenience - Con@ctivity
Efficient filtration- 10-ply stainless steel grease filters
Safe and easy to clean - Miele CleanCover
Stainless-steel grease filters (10-layer)
Con@ctivity
Edge vented
Miele CleanCover
filter saturation indicator
Delayed shutdown
Safety turn off
