PRODUCT DESCRIPTION
Features
TwinBooster
Flexible power: Induction output can be individually distributed or used for one single zone.
Convenient additional functions
Con@ctivity 3.0
Innovative convenience: The ventilation hood reacts automatically to settings on the cooktop.
SmartSelect
Quick and intuitive: power levels and times can be selected separately for each cooking zone.
Safety functions
The safety functions protect you from any nasty surprises - even if your mind is on other things.
Permanent pan recognition
Automatic activation of control elements: Pans already in position are recognized when the cooktop is switched on.
Specifications
Fuel type
Induction
Independent of oven
Yes
Elegant glass ceramic surface
Yes
Ceramic surface color
Black
All-round stainless-steel frame
Yes
Proud installation
Yes
Proud/flush-mounted
-/-
No. of rings
5
Number of cooking areas
0
Maximum number of pans
5
Number of cooking zones/cooking areas
-/-
Position
front left
Type
Variable cooking zone
Size in mm
100-160
Max. rating in W
1400
Max. booster rating in W
1700
Max. TwinBooster rating in W
2200
Position
rear left
Type
Variable cooking zone
Size in mm
160-230
Max. rating in W
2300
Max. booster rating in W
3000
Max. TwinBooster rating in W
3700
Position
Centered
Type
Variable cooking zone
Size in mm
180-280
Max. rating in W
2600
Max. booster rating in W
3000
Max. TwinBooster rating in W
3700
Position
rear right
Type
Variable cooking zone
Size in mm
140-190
Max. rating in W
1850
Max. booster rating in W
2500
Max. TwinBooster rating in W
3000
Position
front right
Type
Variable cooking zone
Size in mm
140-190
Max. rating in W
1850
Max. booster rating in W
2500
Max. TwinBooster rating in W
3000
Networking with Miele@home
Yes
Automatic function
Con@ctivity 3.0
Operation via touchpad sensors
SmartSelect
Display color
Yellow
Permanent pan recognition
Yes
Pan/Pan-size sensors
Yes
Wipe protection
Yes
Recall function
Yes
Minute minder
Yes
Automatic switch-off for all rings
Yes
AutoBoost
Yes
Keep-warm function
Yes
Individual setting options (e.g. acoustic signal tones)
Yes
Stop & Go function
Yes
Easy to clean ceramic glass
Yes
Safety cut-out
Yes
Lock function
Yes
System lock
Yes
Integrated cooling blower
Yes
Overheating protection
Yes
Residual heat indicator
Yes
Width in in. (mm)
36 1/8 (915)
Height in in. (mm)
3 1/8 (78)
Depth in in. (mm)
21 1/2 (544)
Built-in height with mains connection box in in. (mm)
2 7/8 (71)
Weight in lbs. (kg)
46 (21)
Total connected load in kW
9.900-11.500
Voltage in V
208-240
Frequency in Hz
50-60
Power cord length in ft. (m)
3 (1.2)
Dimensions (H x W x D) in mm
3 1/8 (78) x 36 1/8 (915) x 21 1/2 (544)
Cut-out dimensions (W x D) with surface-mounted installation in inches (mm)
34 1/2 in (876 mm) x 20 1/2 in (518 mm)
Cutout dimensions width in in. (mm) with proud-mounted installation
34 1/2 in (876 mm)
Cutout dimensions depth in in. (mm) with proud-mounted installation
20 1/2 in (518 mm)
EAN
4002516611509
Intuitive quick selection via number sequences - Smart Select
Versatile - 5 cooking zones, 1 extra large with diameter of 11 in
With a width of 36 1/8 (915) in (mm) and stainless steel frame for proud-mounting
Shortest heating-up times - TwinBooster
Communication with the ventilation hood - automatic Con@ctivity function
Safety information
Con@ctivity 3.0
SmartSelect
Safety functions
TwinBooster
Permanent pan recognition
Convenient additional functions
Manufactured with great care by Miele & Cie. KG
Manufactured with great care by Miele & Cie
[object Object]
GTIN
04002516611509
EAN
4002516611509
Connection wire
Yes
Manufacturer material number
12074220
Model number
KM 7740 FR
EAN number
4002516611509
Class
Silver
