Summit 23" Built-In Compact Refrigerator, 4.4 cu. ft. Capacity

SKU: AL54PNR
  • Style: Compact
  • Type: Built-In
  • Width: 23.38"
  • Height: 32.00"
  • Depth: 22.63"
  • Energy Star Rated: no
  • Wi-Fi Connected: No
  • Sabbath Mode: Yes
  • ADA Compliant: Yes
  • Total Capacity: 4.40 cu. ft.
  • Defrost: Frost-Free
  • Icemaker: No
  • Dispenser: No
  • Refrigerator Capacity: 4.4 cu. ft.
  • Number of Shelves: 3
Summit |Authorized Dealer
Pre-Order

PRODUCT DESCRIPTION

Summit's AL54 series features built-in undercounter all-refrigerators designed for installation under lower ADA compliant counters, with advanced features for user convenience. Sized with a convenient 24" footprint, the AL54PNR is just 32" high to fit under lower counters complying with ADA guidelines for accessibility. The fully finished black cabinet allows freestanding use, while the front-breathing system also allows this unit to be built-in with minimum clearance. The reversible stainless steel door features a European-style fully articulating hinge for zero clearance opening. We include a 2-piece bracket kit that allows easy installation of overlay panels to create a custom look that can seamlessly blend into your existing cabinetry design (panel size: 28.38" H x 23.4" W; maximum weight: 10 lbs.). This unit has a flush back for easy cleaning and a right angle plug for a better fit. A factory-installed lock is located in the kickplate. Inside, the AL54PNR utilizes frost-free operation with fan-forced cooling to ensure low maintenance and even temperature distribution. Recessed LED lighting offers an attractive yet efficient look. The digital thermostat makes it easy to manage the interior temperature. This unit includes adjustable glass shelves for flexible, spill-proof storage and two large door racks ideal for keeping condiments and bottles in easy reach. The floor is specially slotted to hold bottles in place. Additional features include an open door alarm, high temperature alarm, and Sabbath mode setting that lets you disable some of the electrical elements during periods of observance. With its deluxe style and user-friendly features, this unit is the perfect choice for ADA compliant spaces. Additional styles are available, as well a matching frost-free freezer (model ALFZ53IF). Browse the full Summit line to explore your endless options.

Specifications

GTIN

00761101151267

EAN

0761101151267

UPC

761101151267

Nominal Height

32.0" (81 cm)

Height of Cabinet

32.0" (81 cm)

Nominal Width

24.0" (61 cm)

Width

23.38" (59 cm)

Nominal Depth

23.0" (58 cm)

Depth

22.63" (57 cm)

Depth with door at 90(degree)

46.0" (117 cm)

Capacity

4.4 cu.ft. (125 L)

Defrost Type

Frost-Free

Door

Panel-Ready

Cabinet

Black

US Electrical Safety

ETL

Canadian Electrical Safety

ETL-C

Energy Usage/Year

270.0kWh/year

Amps

1.0

Voltage/Frequency

115 V AC/60 Hz

Weight

100.0 lbs. (45 kg)

Parts & Labor Warranty

1 Year

Compressor Warranty

5 Years

UPC

761101151267

Sabbath Mode

Yes

Door Swing

RHD

Reversible

Yes

Shelf Type

Glass

Shelf Qty

3

Full Door Shelf Qty

2

Adjustable Shelves

Yes

Thermostat Type

Digital

Fan Type

Interior and Exterior

Refrigerant Type

R600a

Refrigerant Amount

0.99oz.

High Side PSI

270.0

Low Side PSI

105.0

Level Legs Qty

4

Interior Light

Yes

Temperature Range

36 to 43 F

Sound Level

33.3dB

Interior Height

24.38" (62 cm)

Interior Width

20.0" (51 cm)

Interior Depth

16.63" (42 cm)

Compressor Step Height

3.25" (8 cm)

Compressor Step Width

20.0" (51 cm)

Compressor Step Depth

5.25" (13 cm)
