PRODUCT DESCRIPTION
Specifications
Nominal Height
79.0" (201 cm)
Height of Cabinet
78.5" (199 cm)
Nominal Width
28.0" (71 cm)
Width
27.5" (70 cm)
Width with Door Open
28.0" (71 cm)
Nominal Depth
26.0" (66 cm)
Depth
26.0" (66 cm)
Depth with Handle
27.75" (70 cm)
Depth with door at 90(degree)
52.0" (132 cm)
Capacity
18.0 cu.ft. (510 L)
Defrost Type
Automatic
Door
White
Cabinet
White
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Amps
1.5
Voltage/Frequency
115 V AC/60 Hz
Weight
270.0 lbs. (122 kg)
Parts & Labor Warranty
2 Years
Compressor Warranty
5 Years
UPC
761101084183
Door Swing
RHD
Reversible
Yes
Shelf Type
Wire
Shelf Qty
7
Adjustable Shelves
Yes
Thermostat Type
Digital
Fan Type
Interior
Refrigerant Type
R290
Refrigerant Amount
1.75oz.
High Side PSI
280.0
Low Side PSI
90.0
Wheel Qty
4
Interior Light
Yes
Temperature Range
2 to 8 C
Interior Height
68.5" (174 cm)
Interior Width
24.13" (61 cm)
Interior Depth
18.75" (48 cm)
Compressor Step Height
6.5" (17 cm)
Compressor Step Width
24.13" (61 cm)
Compressor Step Depth
6.5" (17 cm)
GTIN
00761101084183
EAN
0761101084183
UPC
761101084183
Designed and purpose-built for pharmacy, medication, and vaccine applications to support meeting CDC/VFC/VFA guidelines
The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Powder-coated handle with naturally occurring silver ions to help reduce the spread of germs
Intuitive controls let you adjust the interior temperature between +2 to +8 C
Visual and audible alarms alert if the interior temperature rises or falls out of set range
Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup
Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes)
Battery-powered alarm sounds if the power connection is interrupted
Audible and visual alarm warns if the sensor is disrupted
Control panel requires password entry to adjust the parameters beyond the set point
Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
Control panel provides a readout of the low and high temperatures in 15 minute increments
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Secure three-pronged cord for added unit safety
Walls are constructed from white powder coated metal for added strength and improved temperature retention
Energy efficient LED lighting with internal on/off switch
User-reversible door swing for added flexibility
Quality door gaskets ensure a tight seal for energy savings and improved performance
2 years parts and labor/5 years compressor
Using environmentally friendly hydrocarbons refrigerants for a greener footprint
Solid and glass door choices available from 1 to 15 cu.ft. Browse the Pharma-Vac series for more information
Compatible with Pyxis(R), Omnicell(R), and AcuDose RX(R)
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
