Summit 24" Built-In Wine Cooler, 4.8 cu. ft. Capacity

Nominal Height

34.0" (86 cm)

Height of Cabinet

34.0" (86 cm)

Nominal Width

24.0" (61 cm)

Width

23.63" (60 cm)

Nominal Depth

24.0" (61 cm)

Depth

23.5" (60 cm)

Depth with Handle

25.0" (64 cm)

Depth with door at 90(degree)

45.75" (116 cm)

Capacity

4.76 cu.ft. (135 L)

Defrost Type

Automatic

Door

Glass/SS

Cabinet

Black

US Electrical Safety

ETL

Canadian Electrical Safety

ETL-C

Sanitation

ETL-S

Amps

1.0

Voltage/Frequency

115 V AC/60 Hz

Weight

109.0 lbs. (49 kg)

Parts & Labor Warranty

1 Year

Compressor Warranty

5 Years

UPC

761101066011

Sabbath Mode

Yes

Door Swing

RHD

Reversible

Yes

Shelf Type

Chrome

Shelf Qty

2

Wine Bottle Shelves

Yes

Thermostat Type

Digital

Fan Type

Interior and Exterior

Refrigerant Type

R600a

Refrigerant Amount

1.38oz.

High Side PSI

270.0

Low Side PSI

105.0

Level Legs Qty

2

Interior Light

Yes

Interior Drawers

Yes

Interior Drawers Qty

1

Temperature Range

36(degree)F to 43(degree)F

Sound Level

35.2 dB

Interior Height 1

9.0" (23 cm)

Interior Width 1

19.38" (49 cm)

Interior Depth 1

17.38" (44 cm)

Interior Height

17.63" (45 cm)

Interior Width

19.38" (49 cm)

Interior Depth

17.38" (44 cm)

Compressor Step Height

3.75" (10 cm)

Compressor Step Width

19.38" (49 cm)

Compressor Step Depth

4.63" (12 cm)

GTIN

00761101066011

EAN

0761101066011

UPC

761101066011

ETL-S listed to NSF-7 Standards for use in commercial establishments

Includes an upper slide-out refrigerator drawer and lower front-opening beverage center behind a reversible glass door

Make the best use of space by installing this unit under the counter and flush with other cabinetry

Stainless steel trimmed glass door offers a full display of stored items

Pull-out top drawer provides additional refrigerated space as needed

Upper drawer and lower interior walls are constructed from stainless steel for added strength and easy cleanup

Keyed lock for a secure interior on the lower door (2 keys included)

Electronic controls located in the kickplate ensure easy temperature management, with an external readout of Celsius or Fahrenheit

Reduced user maintenance with automatic defrost

User-reversible door swing allows for more flexibility in placing the unit

Four LED lights in a gentle white hue illuminate the interior for an attractive presentation

Two chrome shelves accommodate a variety of sizes with cantilevered clips to adjust to virtually any position

Upper drawer ships with a removable stainless steel tray with 6 cutouts for small steam pans (included) for easy and organized storage of condiments, sealed garnishes, and other popular bar items

Stainless steel rack can be used in the drawer to keep up to 5 bottles stored at an angle, perfect for keeping open wine or liqueurs in easy reach. The rack can be temporarily screwed in place with included hardware for added stability

Sleek stainless steel handles mounted horizontally add an elegant touch to any setting

Audible alarm will sound if the top drawer or lower door is left ajar for longer than one minute

Unit will retain its last settings when power is restored in the event of power loss

Optional setting lets you disable certain electrical functions during periods of religious observance

Interior walls are perforated ensuring proper ventilation within the unit

Internal fan ensures the interior is evenly cooled from top to bottom

Space-saving design that offers easier cleanability

Allows the unit to be used freestanding

Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

Environmentally friendly design without ozone-damaging chemicals

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
