PRODUCT DESCRIPTION
Specifications
Collection
Fabriano Collection
Origin
Italy
UPC
814830012740
Height
11 1/2"
Width
27 3/4"
Depth
15"
Cut-Out Depth (in.)
13 1/8"
Cut-Out Height (in.)
11 1/2"
Cut-Out Width (in.)
26 5/8"
Dimensions D x W x H
15" x 27 3/4" x 11 1/2"
Product Weight
26.4
Warranty 1 Explained
90 Day Love It Or Leave It
Warranty 2 Explained
2 Year Limited Material And Workmanship for the original owner
ADA Compatible
No
Certification
UL
Prop 65
Yes
Freight Class
85
Shipping Weight
42.9
Carton Height
16"
Carton Width
32"
Carton Depth
20"
Shipping Method
LTL
Amperage
3.6 Amps
Electrical
120V - 60Hz - 3.6 Amps
Frequency (Hz)
60 Hz
Voltage (volts)
120 VAC
Wattage (watts)
430 watts
Appliance Type
Range Hoods
CCC Code Compliance Control
Yes
CFM @ Speed 1
160
CFM @ Speed 2
250
CFM @ Speed 3
395
CFM @ Speed 4
600
Color/Finish
Stainless
Commerical/Residential
Residential
Control Type
Backlit LED
Cooktop Lights
Twin LED Lights
Duct Size
6" Dia.
Ductless Convertible
Ducted or Convertible
Filter Type
Dishwasher Safe Mesh Filters
Install Type
Insert
Installation Type
Insert
LIght Colors
White
Light Type
Twin LED Lights
Lighting Features
3000K LED
Maximum Air Flow Capacity CFM)
600/395
Minimum Air Flow Capacity (CFM)
160
Mounting Height Above Cooktop
27" - 32"
Number of Light Bulbs
2
Number of Speeds
4
Returnable
No
Sones @ Speed 1
1
Sones @ Speed 2
2.5
Sones @ Speed 3
4
Sones @ Speed 4
6.5
Vent Location
Top
Vent Material
Metal
Wireless Compatibility
No
Control Lighting
Blue Backlit
Controls
Code Compliance Electronic Controls
Location
Indoor
Sound Level
1.0-6.5 Sones
Assembled Depth (in.)
No
GTIN
00814830012740
EAN
0814830012740
UPC
814830012740
Backlit Electronic 4 Speed Control with Power Boost
CCC Code Compliance Control - permanently set blower to 395 or 600 CFM to meet local codes
High Efficiency 3000K LED lights brightly illuminate the cooktop
Dishwasher Safe Pro Style Stainless Baffle Filters for efficient filtration
5 Minute Delay Shutoff Timer
XO quality and performance for your custom built-ins
Made In Italy
2 year limited parts and labor warranty for the original owner
NOTE *When CCC(TM) is enabled the number of fan speeds will be reduced to maximum 3 speeds
