PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328005862
GTIN
00646328005862
Country of Origin
Taiwan
Model Group
AK12-B
Model Name
Breeze II
Collection
Core Collection
Replacement Model
AK1236CB
Blower Included
Yes
Internal Blower 1 CFM
400
Internal Blower 1 Min. Sones
1.9
Internal Blower 1 Max Sones
4.5
Minimum CFM
175
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Black
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
1
Watts Per Bulb
5
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200012
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
3.25 x 10
Mounting Height Above Cooktop; IN
24 - 32
Voltage
120
Maximum Amperage
1.4
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
0AK11-21001, 0AK11-20001
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Steel
Wattage
96
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.9375
Net Depth; IN
20.25
Net Height; IN
5.5
Weight; LBS
21.7
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
39.57
Shipping Width; IN
9.37
Shipping Height; IN
24.61
Shipping Weight; LBS
28.3
Shipping Method
Small Parcel
Freight Class
175
Duct Type
Vertical
GTIN
00646328005862
EAN
0646328005862
UPC
646328005862
BriteStrip(TM) LED lighting
Low-profile body
Extra-wide mesh filters
Vertical or horizontal ducting
Multiple color options
Value driven
Optional Ductless Recirculating Kit
