PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Ducted
UPC
646328009457
GTIN
00646328009457
Country of Origin
Taiwan
Model Group
AK65-C
Model Name
Cyclone Under-Cabinet
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1.5
Internal Blower 1 Max Sones
5
Minimum CFM
290
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Black
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Filter-less
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
6, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 32
Voltage
120
Maximum Amperage
2
ADA Compliant
Yes, with optional wall switch
Warranty Parts / Labor
10 / 1
Compatible Appliances
MUA006A, AK00066, AK1710
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Steel
Wattage
240
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.75
Net Depth; IN
22.25
Net Height; IN
6.375
Weight; LBS
30
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
32.1
Shipping Width; IN
9.8
Shipping Height; IN
27.1
Shipping Weight; LBS
35.5
Shipping Method
Small Parcel
Freight Class
175
Certification #
E127334
Clean Filter Alert
No
Duct Type
Vertical
Compatible Mesh or Baffle Filter Part Number
Z0F-B002
GTIN
00646328009457
EAN
0646328009457
UPC
646328009457
Mechanical Slide Controls
3 Speed Levels
LumiLight LED Lighting
Dual-Level Lighting
2 Removable Safety Grilles
Filter-less self-cleaning system
Multiple color options
