PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328008801
GTIN
00646328008801
Country of Origin
Taiwan
Model Group
AK83-B
Model Name
Tornado III Insert
Collection
Pro Collection
Blower Included
No
Internal Blower 1 CFM
390
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
5
Internal Blower 2 CFM
600
Internal Blower 3 CFM
1000
In-Line Blower CFM
1000
External Blower CFM
1000
Minimum CFM
200
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
3
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210040
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
9
ADA Compliant
Yes
Warranty Parts / Labor
10 / 1
Compatible Appliances
CBI-390A, CBI-290C, CBI-600A, PBI-1100B, CBE-1000, PBN-1000A, AK0848AS,AK0848BS, AK0854AS, AK0860AS, MUA006A, MUA010A, 14000005
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
Yes
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
1080
Certification
UL
Nominal Width; IN
38
Net Width; IN
38.4375
Net Depth; IN
15.8125
Net Height; IN
11.4375
Weight; LBS
29.8
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
44
Shipping Width; IN
17
Shipping Height; IN
22
Shipping Weight; LBS
34
Shipping Method
Small Parcel
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Cutout Depth in.
14.75
Cutout Width in.
34.6875
Duct Type
Vertical
GTIN
00646328008801
EAN
0646328008801
UPC
646328008801
LumiLight LED Lighting
Multiple Blower Options
Includes wireless remote control
Professional Baffle Filters
CleanAir Function
Tri-Level Lighting
Optional Liner Accessories Available
