PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Convertible
UPC
646328009556
GTIN
00646328009556
Country of Origin
Taiwan
Model Group
AK90-B
Model Name
Vortex Insert
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
390
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
5
Minimum CFM
200
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
Z0F-B002
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
6
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional wall switch
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-9000, Z0F-C090
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
36
Net Width; IN
34.375
Net Depth; IN
17.5
Net Height; IN
12.3125
Weight; LBS
34.6
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
39.37
Shipping Width; IN
22.64
Shipping Height; IN
19.09
Shipping Weight; LBS
39.5
Shipping Method
Small Parcel
Freight Class
250
Certification #
E127334
Clean Filter Alert
No
Cutout Depth in.
10.5
Cutout Width in.
26.625
Duct Type
Vertical
GTIN
00646328009556
EAN
0646328009556
UPC
646328009556
LumiLight LED Lighting
Hybrid Baffle Filters
Powerful 390-CFM Blower
Mechanical Slide Controls
Adjustable Depth
Dual-Level Lighting
Optional Ductless Recirculating Kit
