PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Convertible
UPC
646328009563
GTIN
00646328009563
Country of Origin
Taiwan
Model Group
AK91-B
Model Name
Monsoon Mini Insert
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
300
Internal Blower 1 Min. Sones
1.5
Internal Blower 1 Max Sones
4
Minimum CFM
150
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
Z0F-B002
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
7, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
2
ADA Compliant
Yes, with optional wall switch
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-9100A, AK00067, Z0F-C091
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
240
Certification
UL
Nominal Width; IN
30
Net Width; IN
28.375
Net Depth; IN
17.875
Net Height; IN
6.125
Weight; LBS
22
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
33
Shipping Width; IN
9
Shipping Height; IN
22
Shipping Weight; LBS
27
Shipping Method
Small Parcel
Freight Class
125
Certification #
E127334
Clean Filter Alert
No
Cutout Depth in.
18.3125
Cutout Width in.
28.625
Duct Type
Vertical
GTIN
00646328009563
EAN
0646328009563
UPC
646328009563
Mechanical Slide Controls
3 Speed Levels
LumiLight LED Lighting
Dual-Level Lighting
Hybrid Baffle Filters
Vertical or horizontal ducting
Optional Ductless Recirculating Kit
