PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328010620
GTIN
00646328010620
Country of Origin
Taiwan
Model Group
AK98-B
Model Name
Spruce Insert Outdoor
Collection
Pro Collection
Blower Included
Yes
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
3.5
Internal Blower 1 Max Sones
9
Minimum CFM
450
Installation Type
Insert
For Outdoor Use
Yes
Color
Stainless Steel
Controls Type
Control Knob
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210031
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
32-42
Voltage
120
Maximum Amperage
8
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
None
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Steel
Wattage
960
Certification
UL
Nominal Width; IN
36
Net Width; IN
34.375
Net Depth; IN
22.5
Net Height; IN
12
Weight; LBS
62
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Shipping Length; IN
16.93
Shipping Width; IN
37.8
Shipping Height; IN
28.54
Shipping Weight; LBS
56.2
Shipping Method
Small Parcel
Freight Class
250
Certification #
E127334
Clean Filter Alert
No
Cutout Depth in.
22.625
Cutout Width in.
34.5
Duct Type
Vertical
GTIN
00646328010620
EAN
0646328010620
UPC
646328010620
LumiLight LED Lighting
High Quality 304S Stainless Steel
Outdoor Rated
Professional Baffle Filters
3-Speed Metallic Knob Controls
Powerful 1200-CFM Blowers
Vertical 10 in. Round Ducting
