PRODUCT DESCRIPTION
Specifications
Brand
Brisas by Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328007378
GTIN
00646328007378
Country of Origin
Taiwan
Model Group
BMI-C
Model Name
Brisas BMI Wall
Collection
Brisas
Replacement Model
BMI-E30DG
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Max Sones
6
Minimum CFM
290
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel + Glass
Controls Type
Capacitive Touch
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
1
Watts Per Bulb
5
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200044
Duct Discharge
Vertical
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
2.6
ADA Compliant
No
Warranty Parts / Labor
1 / 1
Compatible Appliances
BRC-0006, B1C-00MI
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
320
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
19.75
Net Height; IN
23 - 42
Weight; LBS
50
Shipping Length; IN
38.75
Shipping Width; IN
21.9
Shipping Height; IN
25.5
Shipping Weight; LBS
56.7
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328007378
EAN
0646328007378
UPC
646328007378
Capacitive Touch Controls
Airflow Control Technology(TM) (ACT(TM))
LED light strip
Dishwasher Safe Aluminum Mesh Filters
Dual-Level Lighting
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
