PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328008825
GTIN
00646328008825
Country of Origin
Italy
Model Group
DHZ-A
Model Name
Horizon Wall
Collection
Designer Collection
Blower Included
No
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
6
Internal Blower 2 CFM
290
Internal Blower 2 Max Sones
3
In-Line Blower CFM
1000
External Blower CFM
1000
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Matte Black
Controls Type
Capacitive Touch
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
6
Watts Per Bulb
5
Lights Levels
3
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210043
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8
Duct Size; Vertical; IN
6, 8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
6.85
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
2 / 1
Compatible Appliances
CBI-390A, CBI-290C, CBE-1000, CBI-290A, CBI-600A, PBN-1000A, Z0F-C010, Z1C-01HZ, MUA006A, MUA008A, RC-0003
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Steel
Wattage
822
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.375
Net Depth; IN
20.125
Net Height; IN
32.875
Weight; LBS
90
Ceiling Height Minimum
9 ft.
Ceiling Height Maximum
10.5 ft.
Shipping Length; IN
37.9
Shipping Width; IN
37.4
Shipping Height; IN
23.8
Shipping Weight; LBS
121.2
Shipping Method
LTL
Freight Class
250
Certification #
E503546
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008825
EAN
0646328008825
UPC
646328008825
Multiple Blower Options
Capacitive Touch Controls
Tri-Level Lighting
Hybrid Baffle Filters
Optional Wireless Remote Control (RC-0003)
Optional Duct Cover Kit
Optional Ductless Recirculating Kit
