PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328008887
GTIN
00646328008887
Country of Origin
Italy
Model Group
DLA-A
Model Name
Layers Wall
Collection
Designer Collection
Blower Included
No
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
6
Internal Blower 2 CFM
290
Internal Blower 2 Max Sones
3
In-Line Blower CFM
1000
External Blower CFM
1000
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Invisible Touch
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
5
Lights Levels
3
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200066
Duct Discharge
Vertical
Duct Size; Vertical; IN
6, 8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
6.63
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
2 / 1
Compatible Appliances
CBI-390A, CBE-1000, CBI-290A, CBI-600A, PBN-1000A,CBI-290C, Z0F-C010, Z1C-00VS, ZRC-00VS, MUA006A, MUA008A, RC-0003
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
795
Certification
UL
Nominal Width; IN
42
Net Width; IN
41.9375
Net Depth; IN
22
Net Height; IN
27
Weight; LBS
90
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Chimney Width in.
27
Shipping Length; IN
44.6
Shipping Width; IN
21.8
Shipping Height; IN
24.7
Shipping Weight; LBS
83.1
Shipping Method
LTL
Freight Class
250
Certification #
E503546
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008887
EAN
0646328008887
UPC
646328008887
Multiple Blower Options
Invisible Touch Controls
Tri-Level Lighting
Dishwasher Safe Aluminum Mesh Filters
Optional Wireless Remote Control (RC-0003)
Optional Extension Duct Cover Kit
Optional Ductless Recirculating Kit
