PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Downdraft
Vent Type
Convertible
UPC
646328007330
GTIN
00646328007330
Country of Origin
Mexico
Model Group
DLI-A
Model Name
Lift Downdraft
Collection
Designer Collection
Blower Included
No
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
In-Line Blower CFM
1000
External Blower CFM
1000
Minimum CFM
200
Installation Type
Downdraft
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Capacitive Touch
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
1
Watts Per Bulb
14
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200062
Duct Discharge
Horizontal
Duct Size; Horizontal; IN
2 x 20
Duct Size; Vertical; IN
N/A
Voltage
120
Maximum Amperage
4.4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
2 / 1
Compatible Appliances
DBI-600A, PBN-1000A, CBE-1000, ZRC-00LF, DDA-0002, DDS-0030, DDT-0030, 11030132, DDE-0001, 54190053, 54190054, AK00071, AK00072, AK00080, MUA006A, MUA008A, Z0F-C006
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
360
Certification
UL
Nominal Width; IN
36
Net Width; IN
36
Net Depth; IN
2.25
Net Height; IN
18
Weight; LBS
77
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
39
Shipping Width; IN
34.5
Shipping Height; IN
9
Shipping Weight; LBS
85
Shipping Method
LTL
Freight Class
300
Certification #
E109171
Clean Filter Alert
Yes
Duct Type
Horizontal
GTIN
00646328007330
EAN
0646328007330
UPC
646328007330
BriteStrip(TM) LED Lighting
Capacitive Touch Controls
Dual capture zones
Multiple Blower Options
Dual-Level Lighting
Welded and polished body
Optional Ductless Recirculating Kit
