PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328010682
GTIN
00646328010682
Country of Origin
Taiwan
Model Group
ZAN-D
Model Name
Anzio Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200059
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-01AN, Z1C-00AN, Z0F-B002, MUA006A, Z0F-C091, AK1710, RC-0002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
22.0625
Net Height; IN
27 - 48.5
Weight; LBS
36.2
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9.5 ft.
Chimney Height in.
20.7
Chimney Width in.
10.37
Chimney Depth in.
10.62
Shipping Length; IN
34
Shipping Width; IN
23
Shipping Height; IN
27
Shipping Weight; LBS
51
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Duct Type
Vertical
GTIN
00646328010682
EAN
0646328010682
UPC
646328010682
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
Low-profile body
LumiLight LED Lighting
Dual-Level Lighting
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
