PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328001918
GTIN
00646328001918
Country of Origin
Taiwan
Model Group
ZMI-B
Model Name
Milano
Collection
Core Collection
Replacement Model
ZMI-M90CS
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
715
Internal Blower 1 Min. Sones
0.8
Internal Blower 1 Max Sones
5.8
Minimum CFM
250
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic LCD
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200044
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
26 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00MI, Z1C-01MI, RC-0001, MUA008A, Z0F-C002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.1875
Net Depth; IN
20.5
Net Height; IN
26.5 - 50
Weight; LBS
49.3
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
22.5
Chimney Width in.
12.81
Chimney Depth in.
13.62
Shipping Length; IN
24.57
Shipping Width; IN
38.9
Shipping Height; IN
27.09
Shipping Weight; LBS
67
Shipping Method
LTL
Freight Class
300
Duct Type
Vertical
GTIN
00646328001918
EAN
0646328001918
UPC
646328001918
DCBL Suppression System(R)
Bloom(TM) HD LED light bulbs
Airflow Control Technology(TM) (ACT(TM))
Ultra-Quiet Performance
Optional Ductless Recirculating Kit
Optional extension duct cover kit
