PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328009945
GTIN
00646328009945
Country of Origin
Taiwan
Model Group
ZPY-B
Model Name
Pyramid Under-Cabinet
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
400
Internal Blower 1 Min. Sones
2
Internal Blower 1 Max Sones
5
Minimum CFM
210
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200068
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
7, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 32
Voltage
120
Maximum Amperage
2
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00PY, Z0F-C009, AK1710
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
240
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
21
Net Height; IN
7.375
Weight; LBS
31.2
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
34
Shipping Width; IN
13
Shipping Height; IN
26
Shipping Weight; LBS
36
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
No
Duct Type
Vertical
GTIN
00646328009945
EAN
0646328009945
UPC
646328009945
LumiLight LED Lighting
Mechanical Slide Controls
Vertical or horizontal ducting
Dual-Level Lighting
Dishwasher Safe Aluminum Mesh Filters
Perimeter Aspiration System
Optional Ductless Recirculating Kit
