PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328010873
GTIN
00646328010873
Country of Origin
Taiwan
Model Group
ZRV-C
Model Name
Ravenna Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Black Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200044
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00RV, Z1C-00RVBS, MUA006A, Z0F-C002, RC-0002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Steel
Wattage
480
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
19.75
Net Height; IN
23 - 42.5
Weight; LBS
49
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
19
Chimney Width in.
10.37
Chimney Depth in.
10.56
Shipping Length; IN
21.65
Shipping Width; IN
38.58
Shipping Height; IN
25.35
Shipping Weight; LBS
57.9
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328010873
EAN
0646328010873
UPC
646328010873
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
LumiLight LED Lighting
Dual-Level Lighting
Curved Glass Canopy
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
