PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328011603
GTIN
00646328011603
Country of Origin
Taiwan
Model Group
ZSI-ES-B
Model Name
Siena Wall ENERGY STAR(R)
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
290
Internal Blower 1 CFM
400
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50200050
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
26 - 34
Voltage
120
Maximum Amperage
1.2
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
Z1C-00SI, MUA006A, AK1710
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
Yes
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
144
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
21.9375
Net Height; IN
27.5 - 42
Weight; LBS
38.4
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
15
Chimney Width in.
10.5
Chimney Depth in.
8.43
Shipping Length; IN
36
Shipping Width; IN
19
Shipping Height; IN
30
Shipping Weight; LBS
51
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328011603
EAN
0646328011603
UPC
646328011603
ENERGY STAR(R) Certified
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
Hybrid Baffle Filters
3 Year Parts, 1 Year Labor Warranty
LumiLight LED Lighting
Optional Extension Duct Cover Kit
