PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Island
Vent Type
Convertible
UPC
646328008269
GTIN
00646328008269
Country of Origin
Taiwan
Model Group
ZVN-B
Model Name
Verona Island
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Island
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200049
Duct Discharge
Vertical
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00VN, Z1C-00VN, MUA006A, Z0F-C002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
42
Net Width; IN
41.875
Net Depth; IN
27.5
Net Height; IN
28.5 - 50
Weight; LBS
101.100
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
25.5
Chimney Width in.
12.93
Chimney Depth in.
12.75
Shipping Length; IN
30.7
Shipping Width; IN
46.6
Shipping Height; IN
23.6
Shipping Weight; LBS
113.9
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008269
EAN
0646328008269
UPC
646328008269
LumiLight LED Lighting
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
Low-profile body
Ambient Canopy Lighting
Optional Ductless Recirculating Kit
Quick-Lock Installation System
